Technical Information
20
DGC 6xxx
Figure 010-5: Spacer Bar on Rear Panel
4.5 Door Contact Switch (S24) Removal
1. Remove the door; refer to Section 020-4.1.
2. Remove the appliance from its housing unit; see Section 010-4.1.
3. Disconnect the appliance from the power supply.
4. Remove the lid; see Section 010-4.2.
5. Remove the rear/left side panel; refer to Section 010-4.4.
6. Remove the two T20 screws securing the hinge on the left side.
7. Disconnect the switch connections.
8. Lift the hinge up.
9. Unclip the switch assembly at the bottom (Figure 010-6, Item 1) and slide
it out of the hinge assembly.
Figure 010-6: Door Switch Removal
4.6 Cable Duct Removal
1. Remove the appliance from its housing unit; see Section 010-4.1.
