Technical Information
54
DGC 6xxx
Figure 035-9: Steam Generator/Mounting Bracket Assembly, Upside Down
Note:
The steam generator must always be installed at a slight angle. See arrows,
Figure 035-10. This is necessary so that residual water can drain off after a
cooking cycle.
Figure 035-10: Installing the Steam Generator at at Slight Angle
4.5 Convection Fan (M2-2) Removal
1. Remove the door; see Section 020-4.1.
2. Remove the appliance from its housing unit; see Section 010-4.1.
3. Disconnect the appliance from the power supply.
4. Remove the lid; see Section 010-4.2.
5. Remove the rear/left side panel; see Section 010-4.4.
6. Remove the runners from the oven cavity.
7. Remove the two 7mm nuts securing the inner rear panel; take off the
inner rear panel. See Figure 035-11.
1
2
1
