Technical Information
31
DGC 6xxx
Figure 030-3: Convection Element Connections and Retaining Nuts
4.2 Top Heat/Broil Element (R13/R15) Removal
1. Remove the door; see Section 020-4.1.
2. Remove the appliance from its housing unit; see Section 010-4.1.
3. Disconnect the appliance from the power supply.
4. Remove the lid; see Section 010-4.2.
5. Remove the rear/left side panel; refer to Section 010-4.4.
6. Remove the two T20 screws securing the top heat/broil element mounting
bracket to the ceiling of the oven cavity. See Figure 030-4.
Figure 030-4: Top Heat/Broil Element Mounting Bracket Screws
7. Disconnect the top heat/broil element spade connectors from the rear of
1
2
