Technical Information
36
DGC 6xxx
see Figure 030-10, Item 1.
Figure 030-10: Lighting Assembly Nuts
5. Remove the lighting assembly; disconnect it from the power electronic.
6. Remove the halogen bulb.
Note:
Before re-installing the appliance, carry out appropriate electrical safety
tests.
4.6 Convection Heater Temperature Limiter (3F1) Removal
1. Remove the appliance from its housing unit; see Section 010-4.1.
2. Disconnect the appliance from the power supply.
3. Remove the lid; see Section 010-4.2.
4. Remove the rear/left side panel; see Section 010-4.4.
5. Disconnect the electrical connections from the temperature limiter.
6. Remove the 7mm nuts securing the temperature limiter to the rear of the
appliance. See Figure 030-11, Item 1.
7. Remove the temperature limiter from the rear of the appliance.
