4.9 Heat-Flow Temperature Sensor (2R30-10) Replacement
1. Remove the appliance from its housing unit; see Section 010-4.1.
2. Disconnect the appliance from the power supply.
3. Remove the lid; see Section 010-4.2.
4. Remove the right side panel; see Section 010-4.3.
5. Remove the rear/left side panel, if necessary; see Section 010-4.4.
6. Pull off the black hose between the cable duct and the heat-flow fan
housing (Figure 030-13, Item 3).
7. Remove the cable duct; see Section 010-4.6.
8. Disconnect the two red wires from the cooling-air temperature sensor
(Figure 030-13, Item 1).
9. Remove the two T20 screws securing the heat-flow fan housing (see
arrows, Figure 030-14); take out the housing.
Figure 030-14: Heat-Flow Fan Housing Screws
10. Release the retaining pins securing the heat-flow temperature sensor
housing to the metal air shield (see arrows, Figure 030-15); remove the
temperature sensor housing from the air shield.
