Miele DGC 6 Series User Manual

Technical Information
95
DGC 6xxx
Figure 060-4: Surround
Figure 060-5: Bake
Figure 060-6: Browning
Figure 060-7: Convection Broil, Broil
Figure 060-8: Eco Broil
2.4.2 Overview
Operating mode Activated components Heater element
configuration
Rapid heat-up
1
Browning (R13) Figure 060-2
Convection (R14)
Broil (R15)
Convection fan (M2-2)
Cooling fan (1M2-1)
Oven cavity lighting (1H3-2, 2H3-2)
Convection plus Convection (R14) Figure 060-3
Convection fan (M2-2)
Cooling fan (1M2-1)
Oven cavity lighting (1H3-2, 2H3-2)
Surround Browning (R13) Figure 060-4
Bottom (R12)
Cooling fan (1M2-1)
Oven cavity lighting (1H3-2, 2H3-2)
Bake Bottom (R12) Figure 060-5
Cooling fan (1M2-1)
Oven cavity lighting (1H3-2, 2H3-2)
Broil Browning (R13) Figure 060-7
Broil element (R15)
Catalyzer element (R23) (if applicable)
Cooling fan (1M2-1)
Oven cavity lighting (1H3-2, 2H3-2)
