Technical Information
44
DGC 6xxx
1 Technical Data
Air flap motor (M28)
Voltage 12VDC
Power rating 0.16W
Table 035-1: Air Flap Motor Data
Cavity temperature sensor (1R30-10)
Temperature [°F] Resistance [Ω] (in accordance with DIN EN 60751)
32 1000
68 1078
77 1097
86 1117
122 1194
212 1385
302 1573
392 1758
482 1941
572 2120
Table 035-2: Cavity Temperature Sensor Data
Steam generator heater elements (1R25, 2R25, 3R25)
Power rating (3 heater elements connected in parallel) 3 x 1.1kW
Table 035-3: Steam Generator Heater Data
Steam generator temperature regulator (1F1-5, 2F1-5)
Cut-out temperature 428°F
Table 035-4: Steam Generator Temperature Regulator Data
Convection fan (M2-2)
Voltage 220 - 240 VAC 60Hz
Power rating 34 / 16 W
Speed Normal Convection heat or combination mode
Low Steam cooking (for better steam distribution)
Table 035-5: Convection Fan Data
Drain pump (M8)
Power rating 6W
Table 035-6: Drain Pump Data
2 Function
2.1 Cavity Temperature Sensor (1R30-10)
The Pt1000 temperature sensor is a platinum sensor. Its resistance increases
proportionally with the temperature in the cavity; see Table 035-2.
