Technical Information
67
DGC 6xxx
Warning!
When removing the springs, take care that they do not spring out of the
hand when tension is released, and pull them apart slowly; see Figure 040-
5, Item 1.
Figure 040-5: Water Container Spring
5. Hold the left spring firmly and pull the container carefully to the front.
6. Remove the left spring.
7. Hold the right spring firmly and carefully remove the container assembly
to the front.
8. Remove the right spring.
