11 Patient Data Management
Operator’s Manual 11 - 9
• If you use Q-Path function to connect to websites other than Q-Path applications (website
setting is described above), the system will prompt the following information: Only Q-Path
application is allowed to be loaded!
Perform the following procedure:
1. Set the DICOM storage server.
2. Send stored images or worksheet reports from iStation/Review to the Q-Path server.
3. Tap in the top-right corner of the screen and select “Q-Path”.
4. Log in to the Q-Path server through the Q-View browser to check the stored images and
worksheet reports.
If network connection is not normal, the system will prompt “Loading Q-path application,
please wait....”.
5. Tap to exit the function.
11.10 X-Link
The Ultrasound System supports interconnecting information with the bedside device through X-
Link.
The interconnection function of X-Link mainly includes:
Obtaining data: The data of the same patient are matched through network connection;
Using data: Real-time data are obtained and displayed in combination with ultrasound image data;
Storing and reviewing data: The data are stored in combination with the ultrasound image data and
can be reviewed on the ultrasound device.
• Before using this function, ensure that the Ultrasound System and the bedside device are
connected to the same network. For X-Link settings, see “4.6.7 X-Link”.
• This function must be used with the monitor or ventilator of the specified model and version.
Consult Mindray service engineer for details.
Perform the following procedure:
1. Tap [X-Link] and select a Bed No. in Bed Selection window.
2. Select [Physio-View] to activate the function.
3. Select desire physiological signal in Physio-View page. The waveforms of the signals display
on the screen.
4. Adjust the image parameters to obtain optimized images. Select [Save image] or [Save Cine]
to save a image or cine within physiological signals.
5. Select [End Exam] to exit the function.
