3 System Preparation
Operator’s Manual 3 - 5
To login onto the system
Perform the following procedure:
1. Select the login type (Local or LDAP), and user name in the drop-down list.
2. Enter the password and tap [Login].
To change users
Perform the following procedure:
1. Select in the top-right corner of the screen and select [Session Manage].
2. Select [Change User] to bring up the Login dialog box.
3. Select the login type, and user name from the drop-down list.
4. Enter the password and tap [Login].
To modify password
General operators and administrators can modify the password.
Perform the following procedure:
1. Select in the top-right corner of the screen and select [Session Manage] to bring up the
dialog box.
2. If you want to modify the current password, select [Change Password] to bring up the Change
Password dialog box.
3. Enter both the previous and new passwords, and confirm the new password in the dialog box.
4. Select [Confirm] to exit.
To lock the system
Select in the top-right corner of the screen and select [Screen Lock] to lock the system for 10
seconds.
3.3.3 Check the system after it is powered on
Check after the system is powered on:
• There are no unusual sounds or smells indicating possible overheating.
• There are no persistently displayed system error messages.
• There is no evident excessive noise, or discontinuous, absent or black items in the B mode
image.
• Check whether there is abnormal heat on the surface of the probe during an ultrasound
procedure. If you use a probe which is giving off excessive heat, it may burn the patient.
• The display (main screen) can respond functionally.
• The date and time are displayed correctly.
• If you use a probe giving off excessive heat, it may burn the patient.
• If you find anything not functioning properly, this may indicate that the
system is defective. In this case, shut down the system immediately and
contact Mindray Customer Service Department or sales representative.
