12 DICOM/HL7

Operator’s Manual 12 - 5

TIP:

There must be no DICOMDIR/DCMIMG/IHE_PDI files on the external storage media of the same

name as the one being backed up. Otherwise, the backup cannot proceed. Ensure there is enough

storage space, or the backup may fail due to shortage of space.

12.7.2 Media review

Perform the following procedure:

1. Connect the external media with DCM files to the system.

2. Select the data source in iStation screen, and the visible data will be shown.

3. If there are several types of data on the media, the system will ask you to select the format.

Then, tap [DICOMDIR].

12.7.3 Data Restore

NOTE:

Only system-accessible media can be selected.

After the DICOM format data are saved to external media, restore the data to the ultrasound system.

Connect the external media containing DCM files to the system.

1. In iStation, review the data stored on the external media.

2. Select the data to be restored in iStation.

3. Tap [Option] > [Restore] on the iStation screen.

12.8 Structured Report

The Structured Report (SR) can be sent with meeting the following procedures:

• DICOM structured report installed with the corresponding exam mode;

• The state of the SR should be “Cancel” or “Stop”.

• Set the storage option to “Attach SR When Store Images” or “Only Store SR”, see the Setup

chapter.

NOTE:

Only the PACS system from the Medstreaming company (http://www.medstreaming.com/

default.aspx) supports sending self-defined measurements by DICOM SR.

12.8.1 Send structured reports for storage

Perform the following procedure:

1. Create new patient information or load scheduled patient information.

2. Perform measurements.

3. Save the images.

4. End the exam.

5. Open the iStation screen, select the patient exam, and tap [Send To] to open the Send To dialog

box.
