2 - 26 Operator’s Manual
2 System Overview
There is “Display” column you can filter the images by selecting “All Items”, “Selected”,
“Unselected”.
Select [Clear Selected] to clear all selected images.
4. Select [OK] to enter image comparison.
5. Switch the multi-frame cine among the windows to review (single-frame image cannot be
reviewed).
– Select [Dual] to toggle between the two images.
The window with the highlighted “M” mark is the current activated window.
You can select the image to be reviewed at synchronous time when the multi-frame image is
reviewed by using [Sync Play].
6. Save the image if necessary.
7. Select [Return] or [Freeze] to exit image compare.
2.13.2 Frame Compare
Cine compare can only be performed for B/C mode image only. The image on dual/quad window
cannot be compared.
Perform the following procedure:
1. Freeze the image in B/C mode, select [Frame Compare] in “Cine” pageto enter frame
comparison mode.
2. Review the images of different image windows (cine replaying can’t be performed for single-
frame image file), select [Update] or [Dual] to switch the active image window.
3. Save the image if it is necessary.
Measurements, adding comments and body marks are allowed.
4. Select [Frame Compare] again to return to image frozen status; select [Freeze] to enter real-
time imaging.
2.14 Cine Saving
2.14.1 Live Capture
Live capture refers to saving the images or cines in image scanning status; after the storage, the
system continues image scanning.
Live capture can be divided into 2 kinds: retrospective and prospective.
• Retrospective saving is to save the specified images before the current moment; to save the
images stored in the cine memory to the system hard disk.
• Prospective saving is to save the specified images later than the current moment; to save the
images to both the cine memory and the system hard disk.
The live capture time can be set in “Cine” page in the Menu area.
In imaging mode, Select [Pro Capture] / [Retro Capture] in Cine page.
• Select [Save]/[Freeze] to stop saving.
