Operating basics
FRAME PICTURE K
EY ASSIGN. Assigns frame picture files downloaded to the
TG8000 to the OTHER test signal button. This operation is required to output the
frame picture files as a picture (natural picture or test pattern).
Perform the following steps to a ssign a frame picture file to the OTHER test
signal button:
1. Use the left (◄)orright(►) arrow button to select the module to which you
want to assign a frame picture file, and press the ENTER button.
This will display the following submenu. The second line s hows the folder
name that was created when the frame picture file was downloaded to the
TG8000 mainframe.
2. Use the left (◄)orright(►) arrow button to select the folder in which the
frame picture file is saved.
3. Press the ENTER button to assign the frame picture file to the OTHER button.
Refer to the TG8000 PC Tools Technical Reference for detailed information about
creating a frame picture file and downloading the file from a PC to the TG8000
mainframe.
NETWORK INFORMATION
submenu
Use this menu to display all of the current network parameters. Use the left (◄)
or right (►) arrow button to select a network paramete r and display the assigned
address. The following selections are available: IP Address, Subnet M ask ,
Gateway Address, MAC Address,andDHCP Server.
The following figure shows NETWORK INFORMATION submenu.
Figure 2-24: NETWORK INFORMATION submenu
2–38 TG8000 Multiformat Test Signal Generator User Manual
