AVG7 Analog Video Generator module
AVG7 module ma
in menu
Use the AVG7 module main menu to perform the following tasks:
Set the logo, text, or circle overlay on the output signal.
Set the timing offset on the output signal.
Set the APL settings on the output signal.
Scroll the
active picture area of the output signal.
Use the up (▲)ordown(▼) arrow button to scroll through the main menu. The
following figure shows the AVG7 module main menu.
Figure 3-17: AVG7 module main menu
3–36 TG8000 Multiformat Test Signal Generator User Manual
