ATG7 Analog Test Generator module
APL (Bounce): O
utputs the High APL signal and Low APL signal alternately
for the period set in the PERIOD menu item.
Bounce: Outpu
ts the 100% flat field signal and 0% flat field signal alternately
(regardless of the selected signal) for the period set in the PERIOD menu item.
PERIOD. Sets the time interval between two signals when they are output in
APL (Bounce) or Bounce mode. Use the left (◄) or right (►) arrow button to
change the interval. You can set the value from 0.5 seconds to 2.0 seconds in
0.5 second
steps.
ATG7 module factory default settings
The follo
wing table shows the factory default settings for the ATG7 module.
These settings are recalled when you select Factory Default from the PRESET :
RECALL menu item in the mainframe main menu.
Table 3-7: ATG7 module factory default settings
Menu item name Settings
STATUS (Shows the signal format and
signal name output from the SIGNAL
connector)
NTSC SMPTE Color Bars
OUTPUT : BLACK 1 and BLACK 2
FORMAT NTSC
SIGNAL
Black Burst
OUTPUT : BARS
FORMAT NTSC
SIGNAL SMPTE Color Bar
ID TEXT
Status
Disable
TIMING
Vertical
0 Line(s)
Horizontal 0.0000 msec
APL
Mode
APL OFF
Period 1.0 sec
3–28 TG8000 Multiformat Test Signal Generator User Manual
