Tektronix TG8000 User Manual

DVG7 Digital Video Generator module
TIMING. Sets th
e timing offset of the serial digital black outputs relative to the
internal reference signal (frame reset signal). Select this menu item, and then
press the ENTER button to access the TIMING submenu. (See page 3-91.)
VIDEO. Sets the resolution and EDH insertion of the serial digital black signals.
Select this menu item, and then press the ENTER button to access the VIDEO
submenu. (S
ee page 3-92.)
DVG7 module factory default settings
The follow
ing table shows the factory default settings for the DVG7 Generator
module. These settings are recalled when you select Factory Default from the
PRESET : RECALL menu item in the mainframe main menu.
Table 3-18: DVG7 module factory default settings
Menu item name Settings
STATUS 525-270 SMPTE Color Bars
MOVING PICTURE
H Step 0 Sample(s)
V Step 0 Line(s)
Period
1 Frame(s)
Random Disable
OVERLAY : OBJECT
Logo
OVERLAY : BLINK OFF
OVERLAY : LOGO
Logo
OFF
OVERLAY : ID TEXT
Status
Disable
OVERLAY : CIRCLE
Status
Disable
X Position
0.0% APH
Y Position
0.0% APH
Diameter
90% APH
AUDIO : GRP-1 to GRP-4
Status
Disable
Emphasis No Emphasis
Sampling
Frame
Resolution 20 bits
TG8000 Multiformat Test Signal Generator User Manual 3–95
