DVG7 Digital Video Generator module
Table 3-17: DVG7 module signal set assigned to the test signal buttons (cont.)
Button name Signal set Signals in the signal set
SDI SDI Test Equalizer Test, PLL Test, SDI Matrix
OTHER Other Chroma Freq. Resp., Color Palette, FCC
Composite, FCC Multiburst, NTC7 Combination,
NTC7 Composite
625-270 format
COLOR BAR Color Bars 100% Colour Bars, 75% Colour Bars, 100% Colour
Bars Over Red, 75% Colour Bars Over Red
LINEARITY Linearity
10 Step, 3 Channel Ramp, 5 Step, B-Y Valid Ramp,
Limit Ramp, Modulated Ramp, Oversize Ramp,
R-Y Valid Ramp, Shallow Ramp, Shallow Ramp
Matrix, Y Valid Ramp
FLAT FIELD Flat Fields
0% Flat Field, 100% Flat Field, 50% Flat Field, Field
Square Wave
MULTI BURST
Multi Burst
60% Multiburst
SWEEP Sweep 100% Sweep, 60% Sweep, SinX/X
MONITOR
Monitor
100% Red Field, 2 Level Ped. & Pluge, 4 Level Ped.
& Pluge, 75% Red Field, Convergence Pattern,
Gamut Test, Grey Window, White Window
PULSE BAR Pulse & Bar 2T 4T 10T Pulse & Bar, 2T 4T 20T Pulse & Bar
TIMING
Timing 2.5 MHz Bowtie, 500 kHz Bowtie, Active Picture
Timing, Co-Siting Pulse
SDI SDI Test Equalizer Test, PLL Test, SDI Matrix
OTHER Other CCIR 17, CCIR 18, CCIR 330, CCIR 331,
CCIR 331 G2
DVG7 module main menu
Use the DVG7 module main menu to perform the following tasks:
Set the logo, text, or circle overlay on the output signal.
Set the timing offset on the output signals.
Scroll the active p icture area of the output signal.
Enable or disable the output and set parameters for each embedded audio
group.
Enable or disable the video output signal.
