HD3G7 HD 3 Gb/s SDI Video Generator module
HD3G7 module m
ain menu
Use the HD3G7 module main menu to perform the following tasks:
Set the video signal output mode.
Scroll the active p icture area of the output signal.
Change the sample structure and color space.
Control th
e Embedded Audio characteristics: frequency, amplitude, click
rate, and sampling rate.
Set the ti
ming offset of the outputs relative to an internal reference signal or
an external reference signal.
Enable o
r disable the Timecode and set the timecode parameters.
Enable or disable the discrete components of the video output signal.
Enable or disable the user-defined ancillary data payload and set the payload
structure.
Enable or disable the SMPTE 352M Payload identifier.
Set the line, frame, or clock rate as a trigger for an external instrument, such
as an oscilloscope.
Select between a test signal or a black signal for the secondary (SIGNAL 2)
output.
View diagnostics, operation parameters, and CRC error counts from the
video input.
Access output calibration (only available when in factory mode).
Use the up (▲)ordown(▼) arrow button to scroll through the main menu. The
following figures show the HD3G7 module main menu.
TG8000 Multiformat Test Signal Generator User Manual 3–185
