Tektronix TG8000 User Manual

BG7 Black Generator module
FORMAT. Use the
left (◄)orright(►) arrow button to select from the signal
formats in the following table. Press the ENTER button to confirm the selection.
NOTE. When you change the signal format, synchronization shock will occur.
Table 3-13: BG7 module output signal formats
Non-integer HD trilevel sync rate
1
Integer HD trilevel sync rate
1
NTSC NTSC
NTSC-J NTSC-J
PAL PAL
1080 59.94i 1080 60i
1080 23.98sf
1080 50i
1080 29.97p
1080 24sf
1080 23.98p 1080 30p
720 59.94p 1080 25p
1080 24p
720 60p
720 50p
1
The signal formats available in this submenu depend on the HD trilevel sync rate setting (non-integer or integer),
which is set using the Select Output selection in the BG7 module main menu. (See page 3-65, BG7 module
main menu.)
FIEL
D REFERENCE. Use the left (◄)orright(►) arrow button to Enable or
Disable the field reference in the output signal. Press the ENTER button to
confirm the selection.
NOTE. The Field Reference menu item is available only when a non-HD format is
set as the signal format of the selected BLACK output. With Option CB, this menu
item appears only for the BLACK 1 and BLACK 2 outputs.
TG8000 Multiformat Test Signal Generator User Manual 3–67
