Tektronix TG8000 User Manual

BG7 Black Generator module
Vertical: Use t
he left (◄)orright(►) arrow button to adjust the vertical
timing. For NTSC and PAL, you can adjust the timing by ± ½ a color frame.
For HDTV trilevel sync signals, you can adjust the timing by ± ½ a field or
frame (progressive or interlaced signals, respectively). (See Table 3-15.)
Horizontal: Use the left (◄)orright(►)arrowbuttontoadjustthe
horizontal offset. You can set the value from -1 line to +1 line in one clock
steps (18.5 ns for NTSC or PAL, 13.5 ns for HDTV).
Table 3-15: Timing adjustment ranges for BG7 output signals
Format name Vertical line settings Horizontal time settings (μs)
NTSC/NTSC-J
± 525 ± 63.5556
PAL ± 1250 ± 64.0000
1080 60i ± 562 ± 29.6296
1080 59.94i ± 562 ± 29.6593
1080 50i ± 562 ± 35.5556
1080 24sF ± 562 ± 37.0370
1080 23.98sF ± 562 ± 37.0741
1080 30p ± 562 ± 29.6296
1080 29.97p ± 562 ± 29.6593
1080 25p ± 562 ± 35.5556
1080 24p ± 562 ± 37.0370
1080 23.98p ± 562 ± 37.0741
720 60p ± 375 ± 22.2222
720 59.94p ± 375 ± 22.2444
720 50p ± 375 ± 26.6667
3–70 TG8000 Multiformat Test Signal Generator User Manual
