Tektronix TG8000 User Manual

HDVG7 HDTV Digital Video Generator module
Table 3-46: HDVG7 module output signal formats (cont.)
720 29.97p 1035 60i
720 23.98p 720 60p
720 50p
720 30p
720 25p
720 24p
1
The signal formats available in this submenu depend on the HD trilevel sync rate setting (non-integer or integer),
which is set using the HD Rate selection in the HDVG7 module main menu. (See page 3-232, HDVG7 module
main menu.)
SIGNAL. Selects the serial digital black signal to output. Use the left (◄)orright
(►) arrow button to select between Black (serial digital black), 40% Flat Field,
50% Flat Field,and100% Flat Field.PresstheENTER buttontoconfirm
the selection.
AUDIO (EMBEDDED). Sets the parameters for embedded audio on the serial digital
black signals. Use the l eft ( ◄)orright(►)arrowbuttontoselectGroup 1,
Group 2, Group 3,orGroup 4. Select any of the groups, and then press the
ENTER button to access the AUDIO GROUP submenu. (See page 3-241.)
TIMING. Sets the timing offset of the serial digital black outputs r
elative to the
internal reference signal (frame reset signal). Select this menu item, and then
press the ENTER button to access the TIMING submenu. (See page 3-244.)
HDVG7 module factory default settings
The following table shows the factory default settings for the HDVG7 module.
These settings are recalled when you select Factory Default from the PRESET :
RECALL menu item in the mainframe main menu.
Table 3-47: HDVG7 module factory default settings
Menu item name Settings
STATUS 1080 59.94i SMPTE Color Bars
MOVING PICTURE
H Step 0 Sample(s)
V Step 0 Line(s)
Period
1Frame(s)
Random Disable
OVERLAY : OBJECT
Logo
OVERLAY : BLINK OFF
OVERLAY : LOGO
Logo
OFF
TG8000 Multiformat Test Signal Generator User Manual 3–249
