Tektronix TG8000 User Manual

AVG7 Analog Video Generator module
AVG7 module fa
ctory default settings
The following table s hows the factory default settings for the AVG7 Generator
module. These settings are recalled when you select Factory Default from the
PRESET : RECA
LL menu item in the mainframe main menu.
Table 3-9: AVG7 module factory default settings
Menu item name Settings
STATUS NTSC SMPTE Color Bars
MOVING PICTURE
H Step 0 Sample(s)
V Step 0 Line(s)
Period
1Frame(s)
Random Disable
OVERLAY : OBJECT
Logo
OVERLAY : BLINK OFF
OVERLAY : LOGO
Logo
OFF
OVERLAY : ID TEXT
Status
Disable
OVERLAY : CIRCLE
Status
Disable
XPosition
0.0% APH
YPosition
0.0% APH
Diameter
90% APH
TIMING
Vertical
0 Line(s)
Horizontal Coarse
0.0000 ms
Horizontal Fine 0.00 ns
VIDEO
CONFIGURATIO N CH1/2/3 Composites
GBR SYNC Sync ON All Channels
G/Y ON
B/Pb/B-Y ON
R/Pr/R-Y ON
SCH PHASE
0 deg
APL
MODE APL OFF
PERIOD
1.0 s
TG8000 Multiformat Test Signal Generator User Manual 3–47
