Tektronix TG8000 User Manual

HD3G7 HD 3 Gb/s SDI Video Generator module
HD3G7 module f
actory default settings
The following table shows the factory default settings for the HD3G7 module.
These settings are recalled when you select Factory Default from the PRESET :
RECALL menu i
tem in the mainframe main menu.
Table 3-39: HD3G7 module factory default settings
Menu item name Settings
TEST SIGNAL 100% Color Bars
FORMAT
1080 59.94p
SAMPLE STRUCTURE/DEPTH Y CbCr 4:2:2 10b
OUTPUT MODE 3G-Level A (1920 × 1080)
MOVING PICTURE
H Step 0 Sample(s)
V Step 0 Line(s)
Period
1 Frame(s)
Random Disable
AUDIO (EMBEDDED)
Status (Level A)
Group 1–4
Status (Level B)
Group 1–4 Link A
Group 1–4 Link B
Disable
Disable
Disable
Channel
Status
Frequency
Amplitude
Audio Click
Channel Origin
Active
1000
–20 dBFS
OFF
A1-1 through A 4 -4
Sampling
Frame
TIMING
Vertical
0 Line(s)
Horizontal 0.0000 μs
Relative To
Serial (0H)
TIMECODE
Source
Program Time
30 Drop Frame Enable
ATC-LTC OFF
ATC-VITC OFF
