ATG7 Analog Test Generator module
ATG7 Analog Te
st Generator module
This section
describes the module-specific functions of the ATG7 Analog Test
Generator module. Refer to the following locations for additional information
about this module:
ATG7 module connectors for a description o f the rear-panel connectors. (See
page 2-10.)
ATG7 module functional check for a basic procedure to check that the module
is functional. (See page 1-19.)
TG8000 Specifications and Performance Verification Technical Reference for
module specifications and for a detailed procedure to verify that the module
is functioning as specified.
TG8000 Programmer Manual for information about the commands to
remotely control the module.
ATG7 module product description
The ATG7 Analog Test Generator module is an analog test signal generator that
provides NTSC/PAL analog composite signals. The ATG7 module provides the
following features:
SIGNAL output connector, which outputs test signals selected from the
front-panel test signal buttons. You can overlay ID text on this video signal
out
put.
BARS output connector, which outputs NTSC (with or without setup) and
PA
L c olor bars signals, black burst signals, and other video test signals. You
can overlay ID text on this video signal output.
B
LACK 1 and BLACK 2 output connectors, which output NTSC (with or
without setup) and PAL black burst signals, composite sync and composite
blanking signals, NTSC (with or without setup) and PAL subcarrier signals,
H/V drive signals, and other video signals.
Individual format and timing control for each output.
Full remote control using Ethernet interface.
NOTE. PAL-M and PAL-N are not supported by the AGL7, ATG7 and
BG7 modules.
TG8000 Multiformat Test Signal Generator User Manual 3–17
