BG7 Black Generator module
TEST SIGNAL. Us
etheleft(◄)orright(►) arrow button to select the desired
test signal. Press the ENTER buttontoconfirm the selection. The available
signals depend on the selected format (NTSC/NTSC-J or PAL).
NOTE. The Test Signal menu item appears only with Option CB, only for the
BLACK 3 and BLACK 4 outputs, and only when a non-HD format is set as the
signal format of the selected BLACK output.
Table 3-14: BG7 module Option CB test signals (BLACK 3 and BLACK 4 outputs o nly)
NTSC or NTS
C-J format
PAL format
Black Burst
Black Bur
st No Field Reference
Black Burst with Field REF Black Burst
Black Burst with 10 Field ID
100% Color Bars
100% Color Bars 75% Color Bars (100% White)
75% Color Bars (100% White) 100% Color Bar Over Red
SMPTE EG1 Color Bar 75% Color Bar Over Red
40% Flat Field 40% Flat Field
Convergence Convergence
Pluge and Luma Reference Pluge and Luma Reference
Shallow Ramp CCIR 17
NTC7 Combination CCIR 18
NTC7 Composite
TIMING. Press the ENTER button to access the TIMING submenu, which allows
you to set the timing offset for the selected black signal output. (See page 3-69,
BG7 module TIMING submenu.)
TIMECODE. Press the ENTER button to access the TIMECODE submenu, which
allows you to set timecode parameters for the selected BLACK output. (See
page 3-71, BG7 module TIMECODE submenu (GPS7 module only).)
NOTE. TheTIMECODEmenuitemisavailableonlywhenaGPS7moduleis
installed, and only when a non-HD format is set as the signal format of the
selected BLACK output.
The BG7 module hardware must be version 1.2 or above.
3–68 TG8000 Multiformat Test Signal Generator User Manual
