AWVG7 Analog Wideband Video Generator module
NOTE. You can re
set the timing offset to zero by pressing the left (◄)orright(►)
arrow buttons simultaneously.
The adjustmen
t range of the timing offset settings depends on the selected signal
format. (See Table 3-11 on page 3-60.)
Vertical. S
ets the vertical timing offset. Use the left (◄) or right (►) arrow
button to change the timing offset. You can set the value from -1 to +1 frame of
the selected signal format in 1 line steps.
Horizontal coarse. Use the left (◄)orright(►) arrow button to adjust the coarse
horizontal offset. You can set the value from -1 to +1 line of the selected signal
format in
1 clock (18.5 ns) steps.
Horizontal fine. Use t he left (◄)orright(►) arrow button to adjust the fine
horizontal offset. You can set the v alue from -10 ns to +10 ns in 0.1 ns steps.
Table 3-11: Timing adjustment ranges for AWVG7 m odule output signals
Signal format Line settings Coarse settings (μs) Fine settings (ns)
1080 60i YPbPr/GBR
± 562 ± 29.6296 ± 10.00
1080 59i YPbPr/GBR
± 562 ± 29.6593 ± 10.00
1080 50i YPbPr/GBR
± 562 ± 35.5556 ± 10.00
1080 24sF YPbPr/GBR
± 562 ± 37.0370 ± 10.00
1080 23sF YPbPr/GBR
± 562 ± 37.0741 ± 10.00
1080 30p YPbPr/GBR
± 562 ± 29.6296 ± 10.00
1080 29p YPbPr/GBR
± 562 ± 29.6593 ± 10.00
1080 25p YPbPr/GBR
± 562 ± 35.5556 ± 10.00
1080 24p YPbPr/GBR
± 562 ± 37.0370 ± 10.00
1080 23p YPbPr/GBR
± 562 ± 37.0741 ± 10.00
720 60p YPbPr/GBR
± 375 ± 22.2222 ± 10.00
720 59p YPbPr/GBR
± 375 ± 22.4444 ± 10.00
720 50p YPbPr/GBR
± 375 ± 26.6667 ± 10.00
720 30p YPbPr/GBR
± 375 ± 53.3333 ± 10.00
720 29p YPbPr/GBR
± 375 ± 45.9770 ± 10.00
720 25p YPbPr/GBR
± 375 ± 44.4444 ± 10.00
720 24p YPbPr/GBR
± 375 ± 55.5556 ± 10.00
720 23p YPbPr/GBR
± 375 ± 55.6111 ± 10.00
3–60 TG8000 Multiformat Test Signal Generator User Manual
