Tektronix TG8000 User Manual

HDLG7 HD Dual Link Video Generator module
HStep. Sets the
number of samples to be scrolled per frame set in the Period
menu item. Use the left (◄)orright(►) arrow button to change the value. You
can set the value from -252 to +252 in 4-sample steps.
VStep. Sets the number of lines to be scrolled per frame set in the Period menu
item. Use the left (◄)orright(►) arrow button to cha nge the value. You can set
the value from -252 to +252 in 1-line steps.
Period. Sets the time interval between occurrences of the scrolling. Use the left
(◄)orright(►) arrow button to change the value. You can set the value from 1
to 16 in 1-frame steps.
Random. Sets whether or not the picture scrolls randomly. Use the left (◄)or
right (►) arrow button to select between Disable and Enable. Press the ENTER
buttontoconfirm the selection.
HDLG7 module factory default settings
The following table s hows the factory default settings for the HDLG7 module.
These settings are recalled when you select Factory Default from the PRESET :
RECALL menu item in the mainframe main menu.
NOTE. The factory default settings put the HDLG7 module in the Generator mode.
Table 3-44: HDLG7 module factory default settings
Menu item name Settings
STATUS SMPTE RP219 Color Bars 1080 59.94i GBR 4:4:4
12 bits
SAMPLE STRUCTURE/DEPTH 1080 GBR 4:4:4 12 bits
ALPHA CHANNEL DATA Use Y/G Channel
LINK OFFSET
0.0000 ms
2K TEST SIGNAL KEY ASSIGN HD Test Signal
MOVING PICTURE
H Step 0 Sample(s)
V Step 0 Line(s)
Period
1Frame(s)
Random Disable
Converter mode
Normal
Converter embedded audio
LINK A
2K Horizontal/Vertical Gradient offset
Horizontal Gradient offset
16
Vertical Gradient offset
16
TG8000 Multiformat Test Signal Generator User Manual 3–227
