HDVG7 HDTV Digital Video Generator module
HDVG7 HDTV Dig
ital Video Generator module
This section
describes the module-specific functions of the HDVG7 HDTV
Digital Video Generator module. Refer to the following locations for additional
information about this module:
HDVG7 module connectors for a description of the rear-panel connectors.
(See page 2-17.)
HDVG7 module functional check for a basic procedure to check that the
module is functional. (See page 1-40.)
TG8000 Specifications and Performance Verification Technical Reference for
module specifications and for a detailed procedure to verify that the module
is functioning as specified.
TG8000 Programmer Manual for information about the commands to
remotely control the module.
HDVG7 module product description
The HDVG7 HDTV Digital Video Generator module provides 1.485 Gb/s serial
digital video signals in various formats. The module provides the following
features:
Two serial digital video outputs
Two serial digital b lack outputs (Option BK)
Supports SMPTE 274M (1080), SMPTE 240M (1035), and SMPTE 296M
(720)
Overlay of circle, text, or logo o n the video signal
Generates a moving picture by scrolling the active picture area of the output
test signal
Generates timecode with ATC when a GPS7 module is installed
Up to 16 channels of Embedded Audio
Full remote control using Ethernet interface
3–228 TG8000 Multiformat Test Signal Generator User Manual
