Getting started
15. Change the BNC c
able from the upper LINK B connector to the lower
LINK B connector.
16. Repeat steps 10 through 13 for the lower LINK A and LINK B connectors.
Converter function.
17. Set the HDTV digital video generator as indicated below:
Output signal: 100% Color Bars
Format: 1080 59.94i
18. Connect the output connector on the HDTV digital video generator to the HD
SDI IN connector on the HDLG7 using the 75 Ω BNC cable.
19. Press the FORMAT button and use the left (◄)orright(►) arrow button to
select 1080 59.94p, and then press the ENTER button.
20. Press the OTHER button to select the converter mode.
21. Set the waveform monitor to view the INPUT A signal.
22. Check that the appropriate color bars signal is displayed.
23. Set the waveform monitor to view the INPUT B signal.
24. Check that the appropriate color bars signal is displayed.
25. Change the BNC cable from the lower LINK A connector to the upper
LINK A connector.
26. Change the BNC cable from the lower LINK B connector to the upper
LINK B connector.
27. Repeat steps 21 through 24 for the upper LINK A and LINK B connectors.
HDVG7 module functional
check
Use the following procedure to check that the HDVG7 HDTV Digital Video
Generator module is functional:
Required equipment.
HDTV waveform monitor
75 Ω BNC cable
Procedure.
1. Install the module into the TG8000 mainframe. (See page 1-11.)
2
.
P
ower on the TG8000 mainframe by connecting it to the power source. The
initialization process for all installed modules is executed.
3. Check that no error messages appear on the LCD display.
1–40 TG8000 Multiformat Test Signal Generator User Manual
