Getting started
5. If this empty sl
ot will not be used, you must attach a blank panel to the
mainframe to control instrument cooling and EMI emissions.
a. Align the blank panel with the open slot of the mainframe.
b. Tighten the two screws to secure the blank panel to the mainframe.
A blank panel is available as an optional accessory for the
TG8000 mainframe. Refer to Accessories. (Seepage1-4.)
6. If you want to install another module into the slot from which the module is
removed, perform Installing a Module starting at step 4. (See page 1-11,
Module installation and re moval.)
Functional checks
Use the following procedures to check that the TG8000 modules installed in
your instrument are functional.
AG7 module functional
check
Use the following procedure to check that the AG7 Audio Generator module
is functional:
Required equipment.
Digital audio monitor
Oscilloscope
75 Ω BNC cable
75 Ω Termination
Procedure.
1. Install the module into the TG8000 mainframe. (See page 1-11.)
2. Power on the TG8000 mainframe by connecting it to the power source. The
initialization process for all installed modules is executed.
3. Check that no error messages appear on the LCD display.
4. Warm up the instrument for 20 minutes.
5. Press the front-panel MODULE button until the AG7 main menu as shown
below appears .
6. Connect the 1+2 connector to the digital audio monitor using the 75 Ω BNC
cable.
1–16 TG8000 Multiformat Test Signal Generator User Manual
