Getting started
Accessories
The following table lists the standard and optional accessories provided with
the TG8000 mainframe and modules.
Table 1-1: Standard and optional accessories
Accessory Std. Opt.
Tektronix
part nu mb er
TG8000 User Manual (English)
Japanese and Russian language versions are available in
PDF format on the product DVD.
●
071-3036-xx
TG8000 Software Library and Product Documentation DVD
●
063-4440-xx
Rackmounting hardware
●
351-1137-00
Power cord
(See page 1-5, International power cord options.)
●
Varies by
option
Blank rear panel
●
614-1051-00
GPS/GLONASS rooftop antenna (5.0 VDC, 1588 MHz range
signals, F connector) for GPS and GLONASS satellites
1
●
SPG8000ANT
1
The antenna wo
rks with the integrated internal GPS receiver of a GPS7 module.
Options and upgrades
Mainframe and modu le
options
The following table lists the options that can be ordered with the
TG8000 mainframe and modules.
Table 1-2: Instrument and module options
Option Description Instrument/module
3G When you order Option 3G , an option key is
provided which enables 3G-SDI signal generation
on the module for which the option is specified.
SDI7
DBT
When you order Option DBT, an option key is
provided which enables embedded audio Dolby
E program generation on the module for which
the option is specified.
SDI7
D1
When you order Option D1, a Calibration Test
Data Report is provided with the instrument
and/or module for which the option is specified.
TG8000 mainframe,
AG7, AGL7, ATG7, AVG7,
AWVG7, GPS7, HD3G7,
HDLG7, HDVG7, SDI7
BK
When you order Option BK, two serial digital
black s ignal outputs are added to the module.
DVG7, HDVG7
CB When you order Option CB, 10 field ID and
NTSC/PAL color bars signals can be output from
the BLACK3 and BLACK4 outputs.
BG7
1–4 TG8000 Multiformat Test Signal Generator User Manual
