Tektronix TG8000 User Manual

HD3G7 HD 3 Gb/s SDI Video Generator module
To select an ou
tput signal on the HD3G7 module
The HD3G7 module has two modes of operation: converter or generator. To
select an output signal, perform the appropriate procedure below for your selected
mode of opera
tion.
To selec t the Generator
mode on the HD3G7
module
Use this mode to generate either 3 Gb/s SDI or 1.5 Gb/s HD-SDI video test signals.
1. Select the output mode for the signal. (See page 3-163, To select the output
mode on the HD3G7 module.)
2. Select the s ignal format for the output signal. (See page 3-164, To select the
signal format on the HD3G7 module.)
3. Select the sample structure and depth for the output signal. (See page 3-164,
To select the sample structure and depth on the HD3G7 module.)
4. Select the test signal that you want to generate. (See page 3-165, To select the
test signal on the HD3G7 module.)
Table 3-25: HD3G7 module Generator mode – 3G level A (1920 × 1080)
Structure 59.94i 50i 60i 23.98p 24p 25p 29.97p 30p 50p 59.94p 60p 23.98psf 24psf 25psf 29.97psf 30psf
12bXXXXXXXX X XX X X
YCbCr
10bXXXXXXXX X XX X X
YCbCr+A
4:4:4
10bXXXXXXXX X XX X X
12bXXXXXXXX X XX X X
YCbCr
4:2:2
10b X X X
12bXXXXXXXX
GBR
10bXXXXXXXX X XX X X
GBR+A
4:4:4
10bXXXXXXXX X XX X X
Table 3-26: HD3G7 module Generator mode – 3G Level A (1280 × 720)
Structure 59.94i 50i 60i 23.98p 24p 25p 29.97p 30p 50p 59.94p 60p 23.98psf 24psf 25psf 29.97psf 30psf
YCbCr
4:4:4 10b X X X X X X X X
YCbCr+A
4:4:4 10b X X X X X X X X
GBR
4:4:4 10b X X X X X X X X
GBR+A
4:4:4 10b X X X X X X X X
Table 3-27: HD3G7 module Generator mode – 3G Level A (2K × 1080)
Structure 59.94i 50i 60i 23.98p 24p 25p 29.97p 30p 50p 59.94p 60p 23.98psf 24psf 25psf 29.97psf 30psf
XYZ XXXXX X XX X X
GBR
4:4:4 12b
XXXXX X XX X X
3–160 TG8000 Multiformat Test Signal Generator User Manual
