AVG7 Analog Video Generator module
AVG7 Analog Vi
deo Generator module
This section
describes the module-specific functions of the AVG7 Analog Video
Generator module. Refer to the following locations for additional information
about this module:
AVG7 module c onnectors for a description of the rear-panel connectors. (See
page 2-10.)
AVG7 module functional check for a basic procedure to check that the module
is functional. (See page 1-21.)
TG8000 Specifications and Performance Verification Technical Reference for
module specifications and for a detailed procedure to verify that the module
is functioning as specified.
TG8000 Programmer Manual for information about the commands to
remotely control the module.
AVG7 module product description
The AVG7 Analog Video Generator module is an analog video signal generator
which provides analog composite and component video signals in various formats.
The module contains the following features:
Supports the following system formats: NTSC, NTSC no setup, PAL,
525 GBR, 525 YPbPr, 525 Beta, 625 GBR, and 625YPbPr.
Six analog composite or component video outputs.
Outputs a frame picture created by the Frame Picture Generator application.
Overlay of circle, text, or logo on the video signal.
Generates a moving picture by scrolling the active picture area of the output
test signal.
Full remote control using Ethernet interface.
TG8000 Multiformat Test Signal Generator User Manual 3–29
