18. Press the left (
◄)orright(►) arrow button to select Black Burst. Press the
ENTER button to enable the selection.
19. Set the waveform monitor to view the blanking area of the signal.
20. Check that the appropriate black burst signal is displayed.
21. Move the BNC cable from the BLACK 1 connector to the BLACK 2
connector.
22. Press the front-panel BACK button twice to return to the main menu.
23. Repeat steps 14 through 2 0 to check the BLACK 2 output.
BARS output.
24. Move the BNC cable from the BLACK2 connector to the BARS connector.
25. Press the BACK button twice to return to the main menu.
26. Press the left ( ◄)orright(►) arrow button to select BARS.
27. Press the ENTER button. The SELECT FORMAT submenu appears.
28. Press the left (◄)orright(►) arrow but
ton to select NTSC or PAL.
29. Press the ENTER button. The SELECT SIGNAL submenu appears.
30. Press the left (◄)orright(►) arrow button to select 100% Color Bars.
Press the ENTER button to enable the selection.
31. Set the waveform monitor to view the color bars signal.
32. Check that the appropriate color bars signal appears.
AVG7 module functional
check
Use the following procedure to check that the AVG7 Analog Video Generator
module is functional:
Required equipment.
Waveform monitor
75 Ω BNC cable
Procedure.
1. Install the module into the TG8000 mainframe. (See page 1-11.)
2. Power on the TG8000 mainframe by connecting it to the power source. The
initialization process for all installed modules is executed.
3. Check that no error messages appear on the LCD display.
4. Warm up the instrument for 20 minutes.
TG8000 Multiformat Test Signal Generator User Manual 1–21
