Tektronix TG8000 User Manual

HDVG7 HDTV Digital Video Generator module
Table 3-47: HDVG7 module factory default settings (cont.)
Menu item name Settings
OVERLAY : ID TEXT
Status
Disable
OVERLAY : CIRCLE
Status
Disable
X Position
0.0% APH
Y Position
0.0% APH
Diameter
90% APH
AUDIO:GRP-1toGRP-4
Status
Disable
Emphasis No Emphasis
Sampling
Frame
Resolution 24 bits
AUDIO : GRP-1 : CH-1 to CH-4
Frequency 1000 Hz
Amplitude
-20.0 dBFS
Audio Click OFF
TIMING
Vertical
0 Line(s)
Horizontal 0.0000 ms
VIDEO
Y
ON
Pb
ON
Pr
ON
AV Timing Mode
OFF
TIMECODE (requires GPS7 module
be installed in mainframe)
SOURCE
Disable
Option BK
(BLACK) FORMAT
1080 59.94i
(BLACK) SIGNAL
Black
(BLACK) AUDIO : GRP-1 to GRP-4
Status
Disable
Emphasis No Emphasis
Sampling
Frame
Resolution 24 bits
3–250 TG8000 Multiformat Test Signal Generator User Manual
