Tektronix TG8000 User Manual

DVG7 Digital Video Generator module
Table 3-18: DVG7 module factory default settings (cont.)
Menu item name Settings
AUDIO : GRP-1 : Ch-1 to CH-4
Frequency 1000 Hz
Amplitude
-20.0 dBFS
Audio Click OFF
TIMING
Vertical
0 Line(s)
Horizontal 0.0000 μs
VIDEO
Y
ON
Pb
ON
Pr
ON
Resolution 10 bits
EDH
ON
AV Timing Mode
OFF
Option BK
(BLACK) FORMAT
525-270
(BLACK) SIGNAL
Black
(BLACK) AUDIO : GRP-1 to GRP-4
Status
Disable
Emphasis No Emphasis
Sampling
Frame
Resolution 20 bits
(BLACK) AUDIO : CH-1 to CH-4
Frequency 1000 Hz
Amplitude
-20.0 dBFS
Audio Click OFF
(BLACK)TIMING
Vertical
0 Line(s)
Horizontal 0.0000 μs
(BLACK)VIDEO
Resolution 10 bits
EDH
ON
3–96 TG8000 Multiformat Test Signal Generator User Manual
