Tektronix TG8000 User Manual

GPS7 GPS Synchronization and Timecode module
Table 3-24: GPS7 module factory default settings (cont.)
Menu item name
Submenu
item name Settings
SELECT OUTPUT
INPUT-OU TPU T
(Black 1 only)
Output (if allowed)
NOTE. INPUT-OUTPUT selection for Black 1 is
not available on earlier GPS7 modules without the
REF IN input connector.
FORMAT NTSC
Field
Reference
Disable
NOTE. This setting appears for non-HD formats
only.
TIMING
(offset)
Vertical: 0 lines
Horizontal Coarse: 0 μs
Horizontal Fine: 0 ns
TIMECODE Source: Disable
Offset: + 00:00:00:00
30 Drop: Enable 30 Drop Frame
VITC
VITC 1
Output: Disable
Line Number: 14
VITC 2
Output: Disable
Line Number: 16
Black 1
Black 2
Black 3
BLANK ON
REFERENCE
UNLOCK
(Black 2 only)
No
HD
TRI-LEVEL
SYNC RATE
Non-integer
GPS SETUP Antenna Power: Off
Position: Fixed
GPS Constellation: GPS & GLONASS
NOTE. The G PS Constellation selection appears
only for a GPS7 module w ith a GPS/GLONA S S
receiver that is installed in a TG8000 with firmware
version 1.6 or later.
Signal Warning (threshold) :
6–Locked>-----
TG8000 Multiformat Test Signal Generator User Manual 3–155
