Tektronix TG8000 User Manual

SDI7 Dual Channel SD/HD/3G SDI Video Generator module
Table 3-69: SDI7 module factory default settings (cont.)
Menu item name Settings
VIDEO
Y
ON
Cb ON
Cr ON
Edge Filter Enable
AV Timing Mode
OFF
EDH
(SD output mode only)
ON
ANC PAYLOAD
Output
Disable
Parity Automatic
DID 0x101
SDID
0x200
DC
0x101
UDW 0x200
CS
0x200
Auto-Calculate CS
Enable
Line 9
Field 1, Line: 9
Field 2, Line: 9
Start Sample
1928
Video Channel
Luma
Link Location Link A
Stream Location H S Stream 1
SMPTE 352 PAYLOAD
Enable
TRIGGER OUTPUT
Clock System Clock
Source CH1
SECONDARY OUTPUT
Test Pattern
1
The Dolby-E Stream and Dolby Config settings are available only when Option DBT is installed.
3–340 TG8000 Multiformat Test Signal Generator User Manual
