Chapter 7 __________________________________________________ Host Computer Commands
VAISALA______________________________________________________________________ 261
0916-067
7.3 Setup Operating Parameters (SOPRM)
This command is used to configure the Signal Processor. The command
should be issued whenever any of the parameters in the list change. The
default parameter list consists of twenty 16-bit input words. These can be
followed by optional XARG parameters as needed.
0916-068
NTh If 1, then no threshold values are set. This means ignore input words
4, 5, 6, 7, 11, 12, 13, 14, and 18. This is usually used in conjunction with
the THRESH command (see Section 7.29 Set Individual Thresholds
(THRESH) on page 329), when setting individual thresholds.
0916-069
The sample size is continually adjustable from 1 to 256 pulses. However,
during the alternating polarization mode, the sample size must be even. If
an odd value is entered it is rounded up by one in that case.
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | |
Range Avg. (See Text) | | 0 0 0 0 1 | Command
_______________________________|_______|___|___________________|
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | |
Bits for ranges 0.000km to 1.875km | Input 1
_______________________________________________________________|
\_1.875 . \_0.000
.
.
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | |
Bits for ranges 1022.000 km to 1023.875 km | Input 512
_______________________________________________________________|
\_1023.875 \_1022.000
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| |NTh| | 0 0 0 1 0 | Command
|___________________________|___|___________|___________________|
NTh
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| Sample Size | Input 1
|_______________________________________________________________|
To Next Page
