USER’S MANUAL__________________________________________________________________
60 __________________________________________________________________ M211322EN-D
2.14.4 RVP900 Processing Algorithms
Input from Rx Board:
- 16-bit I/Q samples
- Optional dual-channel I/Q samples (for example, for polarization
systems or dual frequency systems)
IQ Signal Correction Options:
- Amplitude jitter correction based on running average of transmit
power from burst pulse
- Interference correction for single pulse interference
- Saturation correction (3 dB to 5 dB)
Primary Processing Modes:
- Poly-Pulse Pair (PPP)
-DFT
- Random or phase coded second trip echo filtering/recovery
- Optional polarization with full co-variance matrix (Z
dr
, PHIDP, LDR,
RHOHV, etc.)
- Optional pulse compression
Processing Options:
- IIR Clutter filters (40 dB and 50 dB) or in pulse pair mode
- Fixed, adaptive width, and GMAP clutter filters in DFT and phase
coded second trip mode
- Velocity de-aliasing: dual PRF velocity unfolding at 3:2, 4:3, and 5:4
PRF ratios or dual PRT velocity processing for selectable inter-pulse
intervals
- Range de-aliasing: phase coding method (random phase for
magnetron) or frequency coding method (not available for
magnetron)
- Scan angle synchronization for data acquisition
- Pulse integration up to 1024
18, 29, 30, 31,
32, 33, 34, 35,
37, 39, 41, 45,
49
GND GND GND
Table 2 RVP901 51-pin Micro-D Summary
Pin # Signal Type Signal Name on J6 Signal Name on J3
