Vaisala RVP900 User Manual

Appendix F ___________________________________________________ RCP902 WSR98D Panel
VAISALA______________________________________________________________________ 463
F.7.4 J8 - RF Test Selection (RF-TEST
SEL)
Connector Type: DB09S
Description: Controls the four position diode switch for the RF test signal
selection.
8 PHASEBIT_N3 H
9 PHASEBIT_P3 L
10 PHASEBIT_N2 H
11 PHASEBIT_P2 L
12 PHASEBIT_N1 H
13 PHASEBIT_P1 L
14 OPFREQREFFL_N
15 OPFREQREFFL_P
16 COHOREFFAIL_P
17 NC
18 NC
19 RFGATE_P L
20 NC
21 NC
22 GND
23 GND
24 PHCOHOSEL_N H
25 PHCOHOSEL_P L
26 PHMODFAIL_N
27 PHMODFAIL_P
28 PHASEBIT_N7 H
29 PHASEBIT_P7 L
30 PHASEBIT_N6 H
31 PHASEBIT_P6 L
32 PHASEBIT_N5 H
33 PHASEBIT_P5 L
34 COHOREFFAIL
35 NC
36 NC
37 RFGATE_N H
Signal Connections Initial Condition
1 DRSIGPOS_P3 L
2 DRSIGPOS_N2 H
3 DRSIGPOS_P2 L
4 DRSIGPOS_N1 H
Signal Connections Initial Condition
