Chapter 7 __________________________________________________ Host Computer Commands
VAISALA______________________________________________________________________ 317
0916-157
0916-158
7.16 Set/Clear User LED (SLED)
This command simply turns the red user LED on and off under program
control. The LED is on during the initial running of internal diagnostics,
and then remains off unless changed by this command. Note that the red
LED can be configured to serve as an internal activity indicator (see TTY
setups), in which case this command has no effect.
0916-159
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| Number of Trigger Angles that Follow (3 – 4096) | Input 1
|_______________________________________________________________|
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| (Ignored) | Input 2
|_______________________________________________________________|
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| First Trigger Angle (16-Bit Binary Angle) | Input 3
|_______________________________________________________________|
.
.
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| Last Trigger Angle (16-Bit Binary Angle) |
|_______________________________________________________________|
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| |LED| | 1 0 0 1 0 | Command
|___________________________|___|___________|___________________|
