USER’S MANUAL__________________________________________________________________
52 __________________________________________________________________ M211322EN-D
0916-023
Figure 16 Reset IP Address
2.11 Support Utilities and Application Software
The RVP900 system includes a complete set of tools for the calibration,
alignment, and configuration of the RVP900. These includes the following
utilities:
- ascope—A comprehensive utility for manual signal processor control
and data display of moments, times series, and Doppler spectra.
Ascope includes a realistic signal simulator capable of producing both
first and second trip targets. Recording/playback of time series and
moments is also included.
- dspx—An ASCII, text-based program to access and control the signal
processor, including providing access to the local setup menus
- speed—A performance measuring utility
- DspExport—Exports the RVP900 to another workstation over the
network. This allows utilities on a remote network to run locally, as
opposed to exporting the utility display window over the network.
- setup—Interactive GUI for creating/editing the RVP900
configuration files
- zauto—Calibration utility for use with a test signal generator
These tools can be run locally on the RVP900 or over the network from a
central maintenance facility. The DspExport utility improves the
performance of the utilities for network applications by letting them be run
on the workstation that is remote from the RVP900. The standard
X-Window export is supported, but requires more bandwidth.
