F.7.9 J14 - DCU Serial I/O (SERIAL-IN)
Connector Type: DB15P
Description: DCU serial line from the WSR98D.
13 NC
14 DAU_RX
15 GND
Signal Connections Initial Condition
1NC
2NC
3NC
4NC
5NC
6NC
7NC
8NC
9NC
10 NC
11 DCU_TX
12 NC
13 NC
14 DCU_RX
15 GND
Signal Connections Initial Condition
