Figure 86 RxNet7 Front Panel
0916-023
Figure 87 Rack Side Perspective View
G.6.3 Connector Locations
All the connectors on the RCP903 ASR9-WSP Panel that interface with
the radar are located on the front of the mounting position.
0916-023
Figure 88 Panel Connector Locations
NOTE
This is intended to mount from the rear of the rack.
