USER’S MANUAL__________________________________________________________________
462 _________________________________________________________________ M211322EN-D
F.7.2 J4 - Receiver Protector (Rx PROT)
Connector Type: DB09S
F.7.3 J7 - RF Generator (RF-GEN)
Connector Type: DB37S
Description: RF generator control, status, and phase modulation
26 MOD_DISCHARGE_TRG_N L
27 NC
28 SHORT_BEAM_PULSE_SEL_N L
29 SHORT_RF_PULSE_SEL_N L
30 PULSE_RATE_IN_N0 L
31 PULSE_RATE_IN_N1 L
32 PULSE_RATE_IN_N2 L
33 TRIGGER_CHARGE_TRG_P H
34 NC
35 NC
36 NC
37 NC
Signal Connections Initial Condition
1
VCC3_OUT
*
2 RCVR_PROTECT_RSP_P
3 RCVR_PROTECT_RSP_N
4 RCVR_PROTECT_CMD_P H
5 RCVR_PROTECT_CMD_N L
6NC
7GND
8GND
9NC
*
VCC3_OUT is designed to provide 200 mA of current from the 5V
supply on the panel.
Signal Connections Initial Condition
1NC
2NC
3NC
4CHANFAIL_N
5CHANFAIL_P
6 PHASEBIT_N4 H
7 PHASEBIT_P4 L
Signal Connections Initial Condition
