Startup Procedure and Test Run
4
4.4 Keypad Operation
YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference 149
5. Push or to select [Verify (drive → keypad)], then push .
6. Push or to select the data to verify, then push .
The keypad shows “End” when the parameter settings backed up in the keypad agree with the parameter settings
copied to the bypass.
Note:
The keypad shows vFyE [Parameters do not Match] when the parameter settings backed up in the keypad do not agree with the parameter
settings copied to the drive. Push one of the keys to return to the screen in Step 6.
◆ Delete Parameters Backed Up to the Keypad
This procedure deletes the parameters that were backed up to the keypad.
1. Push (Home) to show the HOME screen.
Note:
• When the drive is in HOME Mode, the screen shows [Home] in the upper right-hand corner of the screen.
• If the screen does not show [Home] for , push (Back), and then push to show [Home].
2. Push (Menu).
3. Push or to select [Parameter Backup/Restore], then push .
To Next Page
