2.8 Exterior and Mounting Dimensions
56 YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference
Bypass
Model
H6BP
Dimensions
in (mm)
Wt. (lb)
W H D W1 W2 H1 H2 H3 H4 D1 D2
B065
12.52
(318.1)
52.06
(1322.3)
16.60
(421.7)
11.86
(301.3)
9.89
(251.2)
51.06
(1296.9)
36.00
(914.4)
8.03
(204)
0.50
(12.7)
14.26
(362.3)
12.35
(313.8)
121
B077
12.52
(318.1)
52.06
(1322.3)
16.60
(421.7)
11.86
(301.3)
9.89
(251.2)
51.06
(1296.9)
36.00
(914.4)
8.03
(204)
0.50
(12.7)
14.26
(362.3)
12.35
(313.8)
135
