5.7 H: Terminal Functions
274 YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference
■ 188 and 1A8: Inverse Inputs of 88 and A8
Setting Value Function Description
188 and 1A8 Inverse Inputs of 88 and A8 Sets the function of the selected MFDI to operate inversely. To select the function for inverse input, enter two digits of 88 or A8 for
the “xx” in ”1xx”.
For example, to use the inverse input of 88 [Thermostat Fault], set H1-xx = 188.
◆ H2: Digital Outputs
H2 parameters set the MFDO terminal functions.
■ H2-01 to H2-03 Terminal M1-M2, M3-M4, M5-M6 Function Selection
The drive has three MFDO terminals. Table 5.39 shows the default function settings for the terminals.
Table 5.39 MFDO Terminals Default Function Settings
No. Name Default Function
H2-01 Term M1-M2 Function Selection 0 During Run
H2-02 Term M3-M4 Function Selection 1 Zero Speed
H2-03 Term M5-M6 Function Selection 2 Speed Agree 1
Refer to Table 5.40 to set H2-xx [MFDO Function Selection].
Table 5.40 MFDO Setting Value
Setting Value Function Reference
0 During Run 280
1 Zero Speed 280
2 Speed Agree 1 280
3 User-Set Speed Agree 1 281
4 Frequency Detection 1 281
5 Frequency Detection 2 282
6 Drive ready 282
7 DC Bus Undervoltage 283
8 During Baseblock (N.O.) 283
9 Frequency Reference from Keypad 283
B Torque Detection 1 (N.O.) 283
C Frequency Reference Loss 283
E Fault 283
F
*1
Not Used 283
10 Alarm 284
11 Fault Reset Command Active 284
12 Timer Output 284
13 Speed Agree 2 284
14 User-Set Speed Agree 2 284
15 Frequency Detection 3 285
16 Frequency Detection 4 285
17 Torque Detection 1 (N.C.) 286
18 Torque Detection 2 (N.O.) 286
19 Torque Detection 2 (N.C.) 286
1A During reverse 286
Setting Value Function Reference
1B During Baseblock (N.C.) 287
1E Executing Auto-Restart 287
1F Motor Overload Alarm (oL1) 287
20 Drive Overheat Pre-Alarm (oH) 287
21 Safe Torque OFF 287
2F Maintenance Notification 288
37 During Frequency Output 288
38 Drive Enabled 288
39 Watt Hour Pulse Output 288
3A Drive Overheat Alarm 289
3D During Speed Search 289
42 Pressure Reached 289
4C During Fast Stop 289
4D oH Pre-Alarm Reduction Limit 289
51 Sequence Timer 1 289
52 Sequence Timer 2 289
53 Sequence Timer 3 290
54 Sequence Timer 4 290
58 UL6 Underload Detected 290
60 Internal Cooling Fan Failure 290
62 Modbus Reg 1 Status Satisfied 290
63 Modbus Reg 2 Status Satisfied 290
69 External Power 24V Supply 290
6A Data Logger Error 290
71 Low PI2 Control Feedback Level 290
