5.7 H: Terminal Functions
306 YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference
Note:
Make sure that you also set jumper S5 on the control circuit terminal block when you change this parameter.
0 : 0 to 10 Vdc
2 : 4 to 20 mA
■ H4-08: Terminal AM Signal Level Select
No.
(Hex.)
Name Description
Default
(Range)
H4-08
(0424)
Terminal AM Signal Level
Select
Sets the MFAO terminal AM output signal level. 0
(0, 2)
Note:
Make sure that you also set jumper S5 on the control circuit terminal block when you change this parameter.
0 : 0 to 10 Vdc
2 : 4 to 20 mA
■ H4-20: Analog Power Monitor 100% Level
No.
(Hex.)
Name Description
Default
(Range)
H4-20
(0B53)
Analog Power Monitor
100% Level
Sets the level at 10 V when you set U1-08 [Output Power] for analog output. 0.00 kW
(0.00 - 650.00 kW)
Note:
• When H4-20 = 0.00 kW, the output power monitor 10 V level = motor rated power.
◆ H5: Memobus/Modbus Communication
H5 parameters configure the bypass to use MEMOBUS/Modbus communications.
You can use the MEMOBUS/Modbus protocol over the RS-485 port (terminals D+ and D-) in the bypass to use serial
communication with programmable controllers (PLC).
■ H5-01: Drive Node Address
No.
(Hex.)
Name Description
Default
(Range)
H5-01
(0425)
Drive Node Address Sets the communication slave address for drives. 1FH
(Determined by protocol)
Note:
• Setting range differs by protocol:
–BACnet: 0 to 7F
–P1: 0 to FF
–N2: 0 to FF
–Modbus: 0 to FF
• Restart the drive after you change the parameter setting.
• Setting 0 will not let the drive respond to MEMOBUS/Modbus communications.
To enable the drive to communicate with the controller (master) over MEMOBUS/Modbus communications, you
must set the drive with a slave address. Set H5-01 ≠ 0.
Set a slave address that is different from other slave devices.
■ H5-02: Communication Speed Selection
No.
(Hex.)
Name Description
Default
(Range)
H5-02
(0426)
Communication Speed
Selection
Sets the communications speed for MEMOBUS/Modbus communications. 3
(Determined by protocol)
